Product Introduction of YT-HM Type
The YT-HM mobile ammonia mass spectrometry leak detector is a leak detector with high sensitivity, fast speed and wide measurement range. The unique and classic appearance design, equipped with a 7-inch color touch screen adjustable trolley, makes it convenient to move, use and store. It is equipped with a turbine high vacuum molecular pump with a rotational speed of 1500 revolutions per second and an external double-rotary vane mechanical pump, which can quickly reach the leak detection state. A brand-new mass spectrometry technology with 180° ionization deflection and an all-metal sealed structure. The operation is simple and the one-click fully automatic control is widely used in the new energy industry, refrigeration industry, precision processing, high vacuum equipment, electrical and power industry, etc
Product Introduction of YT-HM Type
The YT-HM mobile ammonia mass spectrometry leak detector is a leak detector with high sensitivity, fast speed and wide measurement range. The unique and classic appearance design, equipped with a 7-inch color touch screen adjustable trolley, makes it convenient to move, use and store. It is equipped with a turbine high vacuum molecular pump with a rotational speed of 1500 revolutions per second and an external double-rotary vane mechanical pump, which can quickly reach the leak detection state. A brand-new mass spectrometry technology with 180° ionization deflection and an all-metal sealed structure. The operation is simple and the one-click fully automatic control is widely used in the new energy industry, refrigeration industry, precision processing, high vacuum equipment, electrical and power industry, etc
◆ Multiple measurement units are available for selection, and the detection data is directly output
The minimum detectable leakage rate is high, and the sensitivity reaches 10 ranges
The unique gas path design can prevent impurities from entering the instrument.
◆ Double iridium filament, with two switching modes: automatic/manual.
◆ Automatic zero adjustment, automatic calibration and remote operation are all available.
◆ Multi-mode function input and output, easy connection to various automated devices.
The minimum detectable leak rate is 5 × 10^(-13)Pa·m^3/S
The leakage rate display range is from 1 × 10(-3) to 1 × 10^(-13)Pa·m^3/S
The start-up time is ≤2 minutes
The response time is ≤1 second
The maximum pressure at the leak detection port is 1500Pa
The power supply requirement is 220V+10%/50Hz
Display units: Pa·m/S, mbar·l/s, atm·cc/s, ppm
The working environment temperature is 10-40℃, and the corresponding humidity is no more than 80%
Weight: 80KG
